Class 2 Oxidising Gas Sign

Class 2 Oxidising Gas Sign

Class 2 Oxidising Gas Sign – The “Class 2 Oxidising Gas Sign” is a valuable tool to help protect personnel’s health and safety and is not a replacement for the preventive measures needed to minimise or remove hazards. The “Class 2 Oxidising Gas Sign” features a symbol of the skull and crossbones above the word toxic gas accompanied by a big, bold number 2. The sign features a white backdrop with black text and symbols.

FAQ

1. What does a Class 2 Oxidising Gas Sign mean?
   It indicates gases such as oxygen, nitrous oxide, or compressed air that can intensify fires or explosions when combined with flammable materials.

2. Where should Class 2 Oxidising Gas Signs be displayed?
   They must be placed on transport vehicles, cylinder storage areas, and workplaces handling oxidising gases to comply with NZ and Australian dangerous goods regulations.

3. What size sign do I need?
   Transport placards must be 250 mm minimum. Smaller 120 mm versions are useful for gas cylinder cages or cabinets, while larger 400–800 mm options are best for depots and outdoor areas.

Note on 120 mm size: The 120 mm option is not compliant for transport placards, as NZ regulations require a minimum of 250 mm per side for vehicle use. However, it is very useful for small-scale applications such as cylinder cages, storage cabinets, and indoor warning signage where space is limited.

Note on larger sizes (400 mm – 800 mm): While 250 mm is the minimum required size for transport placards, larger signs (400 mm, 600 mm, 800 mm) are recommended for warehouses, depots, bulk storage areas, and outdoor use. The extra size improves long-distance visibility and makes hazards clear to staff, visitors, and emergency responders.

“Handling LPG or oxygen? See how Class 2 fits into the bigger DG picture in our Dangerous Goods Class Guide — no gas about it.”

How to choose the right mounting options.

Corflute: short term less than 2 years outdoors

Thin PVC: Medium term, more than 2 years

ACM: Long term 5 years or more

Supplied as a sticker:

long term digital print laminated for long term use. With a life of 5 years or more. We use a Hi Tac vinyl which allows it to be applied most surfaces.

Magnetic mounting option for the Class 2 Oxidising Gas Sign

Flexible, vehicle-grade magnetic placards with the Class 2 Oxidising Gas Sign printed on premium vinyl, laminated, and mounted to automotive magnetic sheeting. They stick to ferrous steel panels and remove without residue—ideal for vehicles that only carry DG sometimes.

Who they’re for

• Contractors / couriers who transport Dangerous Goods occasionally

• Hire or multi-use vehicles (no permanent signage)

• Sites that swap classes depending on load (quick changeover)

• Size: 250 × 250 mm (meets common road minimums).

• Magnet: vehicle-grade sheet, 0.8–1.0 mm thick (30–40 mil), high-energy.

• Face film: outdoor self-adhesive vinyl + UV laminate (gloss).

• Operating temp: suitable from winter cold to summer heat (typical automotive range).

• Print: high-contrast black/white artwork.

Where they work (and don’t)

• Works on: painted steel panels that are flat, clean, and smooth.

• Doesn’t work on: aluminium, stainless, plastics, composites, heavy body filler; vinyl wraps, ceramic coatings, heavily textured paint.

• If customers have aluminium doors/ute trays, suggest self-adhesive or rigid ACM instead.

Fitment checklist

1. Clean & dry the panel (no wax/polish).

2. Warm, flat magnet—no curl.

3. Apply to flat steel only; press from centre out.

4. Do not bridge panel gaps, ribs or sharp curves.

5. Remove daily to clean/dry both surfaces; store flat.

6. In heavy rain/highway speeds, check edges haven’t lifted.

Care & maintenance

• Remove and wipe after wet weather; store flat (never rolled tight).

• Move position slightly each week to avoid differential fading.

• Avoid use on freshly resprayed paint (allow full cure).

Compliance note

• Magnet is a mounting method. The operator must ensure placards are the correct class, size, and securely affixed for the journey. Some carriers or site rules may require permanent/rigid placards—check your procedure.
