Spontaneously Combustible Sign Class 4

Hazardous Sign – Spontaneously Combustible Sign Class 4

Spontaneously Combustible Sign Class 4 –This diamond identifies Class 4.2 – Spontaneously Combustible dangerous goods (self-heating solids/liquids that can ignite on contact with air or after storage). Use it on vehicles, containers, tanks, cages, storage rooms, and transfer areas so drivers, staff and emergency responders instantly understand the hazard.

Note on 120 mm size: The 120 mm option is not compliant for transport placards, as NZ regulations require a minimum of 250 mm per side for vehicle use. However, it is very useful for small-scale applications such as cylinder cages, storage cabinets, and indoor warning signage where space is limited.

Note on larger sizes (400 mm – 800 mm): While 250 mm is the minimum required size for transport placards, larger signs (400 mm, 800 mm) are recommended for warehouses, depots, bulk storage areas, and outdoor use. The extra size improves long-distance visibility and makes hazards clear to staff, visitors, and emergency responders.

FAQ

Q1: What’s the difference between Class 4.1, 4.2 and 4.3?

• 4.1 Flammable solids ignite easily from an external source.

• 4.2 Spontaneously combustible (this sign) self-heat and can ignite without an external flame.

• 4.3 Dangerous when wet react with water to release flammable gas. Use the placard that matches your SDS/transport documents.

Q2: What size do I need for transport?
NZS 5433 requires 250 mm minimum for vehicle placards. Choose 400–800 mm where longer viewing distance helps (truck curtains, gates, depots).

Q3: Can I use a magnetic version on my truck?
Yes—if the mounting surface is ferrous steel, our laminated magnetic placard is ideal for temporary or rotating loads. For aluminium or composite bodies, choose vinyl or ACM panel with fixings.

For more information check out these links

• WorkSafe NZ – Hazardous Substances Management
  👉 WorkSafe NZ – Hazardous substances

• EPA NZ – HSNO Act guidance
  👉 EPA NZ – Hazardous Substances and New Organisms (HSNO) Act

• United Nations GHS
  👉 UN – Globally Harmonized System (GHS)

• Why you need the correct Hazard sign

Check out our: Complete Guide to Dangerous Goods Placards (NZ & AU)

How to choose the right mounting options.

Corflute: short term less than 2 years outdoors

Thin PVC: Medium term, more than 2 years

ACM: Long term 5 years or more

Supplied as a sticker:

long term digital print laminated for long term use. With a life of 5 years or more. We use a Hi Tac vinyl which allows it to be applied most surfaces.

Magnetic mounting option for the Spontaneously Combustible Sign Class 4 sign

Flexible, vehicle-grade magnetic placards with the Spontaneously Combustible Sign Class 4 sign printed on premium vinyl, laminated, and mounted to automotive magnetic sheeting. They stick to ferrous steel panels and remove without residue—ideal for vehicles that only carry DG sometimes.

Who they’re for

• Contractors / couriers who transport Dangerous Goods occasionally

• Hire or multi-use vehicles (no permanent signage)

• Sites that swap classes depending on load (quick changeover)

• Size: 250 × 250 mm (meets common road minimums).

• Magnet: vehicle-grade sheet, 0.8–1.0 mm thick (30–40 mil), high-energy.

• Face film: outdoor self-adhesive vinyl + UV laminate (gloss).

• Operating temp: suitable from winter cold to summer heat (typical automotive range).

• Print: high-contrast black/white artwork.

Where they work (and don’t)

• Works on: painted steel panels that are flat, clean, and smooth.

• Doesn’t work on: aluminium, stainless, plastics, composites, heavy body filler; vinyl wraps, ceramic coatings, heavily textured paint.

• If customers have aluminium doors/ute trays, suggest self-adhesive or rigid ACM instead.

Fitment checklist

1. Clean & dry the panel (no wax/polish).

2. Warm, flat magnet—no curl.

3. Apply to flat steel only; press from centre out.

4. Do not bridge panel gaps, ribs or sharp curves.

5. Remove daily to clean/dry both surfaces; store flat.

6. In heavy rain/highway speeds, check edges haven’t lifted.

Care & maintenance

• Remove and wipe after wet weather; store flat (never rolled tight).

• Move position slightly each week to avoid differential fading.

• Avoid use on freshly resprayed paint (allow full cure).

Compliance note

• Magnet is a mounting method. The operator must ensure placards are the correct class, size, and securely affixed for the journey. Some carriers or site rules may require permanent/rigid placards—check your procedure.

For further information go to the Worksafe website https://www.worksafe.govt.nz/topic-and-industry/hazardous-substances/managing/hazardous-substances-signs/

For further information go to the Worksafe website https://www.worksafe.govt.nz/topic-and-industry/hazardous-substances/managing/hazardous-substances-signs/

NZS/AS 1319:1994 advocates simplicity and clarity in safety signage. To be effective, they should be easy to read and interpret at a glance.

The Standard is about the use of legible text and appropriate, simple symbols.

By simplifying the message, it reduces the risk of misinterpretation, which increases the chances of the sign’s warning or instruction being followed.

Enhancing the signs visibility through placement and colour

Placement and visibility will play a crucial role in the efficiency of safety signs.

The standard states that signs must be positioned near the hazard they are warning about, which ensures that the safety message is relevant. Also it advocates the use of contrasting colours for the background and lettering. This attention to the colour scheme will increase visibility and readability from a reasonable distance, which ensures the message is accessible.
