Which Diesel Sign Do I Need?

Which Diesel Sign Do I Need?

Hazchem 3Z 1202 vs Hazchem 3Z 3082 vs UN 3082 — Explained

Diesel signage can be confusing that’s why we created the “Which Diesel Sign Do I Need?” resource — there are multiple codes, colours, and layouts that all look similar but serve very different purposes. If you’re not sure whether you need a Hazchem 3Z 1202 sign, a Hazchem 3Z 3082 sign, or just a UN 3082 environmental placard, this guide will make it clear.

Getting this right isn’t just good practice — it’s a compliance requirement under HSNO, NZS 5433:2020, and NZS/AS 1319:1994.

🔎 Quick Comparison Table

Sign TypeCode / Number DisplayedPurposeWhere to UseCompliance
Hazardous 3Z 1202 Diesel SignHazchem 3Z + UN 1202Identifies diesel as a Class 3 Flammable Liquid and instructs fire crews to use foam or water fog.Bulk diesel tanks, road tankers, depot entrances.HSNO, NZS 5433 (Transport of Dangerous Goods on Land), NZS/AS 1319:1994.
HAZCHEM 3Z UN 3082 Diesel SignHazchem 3Z + UN 3082Identifies diesel as an environmentally hazardous substance (Class 9) and provides Hazchem firefighting guidance.Sites near waterways, environmentally sensitive areas, or where runoff containment is required.HSNO, NZS 5433, NZS/AS 1319:1994.
UN 3082 Environmental PlacardUN 3082 only (black/white Class 9 symbol)Shows diesel is environmentally hazardous but does not include Hazchem info.Tankers, tanks, or depots where only UN hazard classification is required.NZS 5433 (Class 9 placard requirement), HSNO.

🏭 When to Use Each Sign

  • Use Hazchem 3Z 1202 when you’re identifying diesel as a flammable liquid — this is the most common requirement for bulk tanks and tankers.

  • Use Hazchem 3Z UN 3082 when environmental protection is also a priority, such as near stormwater drains, rivers, or sensitive sites.

  • Use UN 3082 Placards when your main goal is to show compliance with Class 9 labelling for transport or storage.

📷 Visual Examples

hazardous 121hazardous 0543Z 3082 Diesel HAZCHEM Sign

✅ Compliance Notes

All three options are compliant with HSNO and NZS 5433:2020 when displayed in the correct size for viewing distance:

  • 300 × 225 mm: up to 5 m viewing

  • 450 × 337 mm: up to 10 m viewing

  • 600 × 450 mm: up to 15 m viewing

  • 800 × 600 mm: up to 20 m viewing

  • 1200 × 800 mm: up to 30 m viewing (ideal for site entrances or where long-distance legibility is required)

Signs must be clean, legible, and not obstructed. Magnetic versions are ideal for vehicles and can be removed when not carrying diesel.
